1000VDC 400A NH2XL Solar PV Fuse Base
  • 1000VDC 400A NH2XL Solar PV Fuse Base1000VDC 400A NH2XL Solar PV Fuse Base
  • 1000VDC 400A NH2XL Solar PV Fuse Base1000VDC 400A NH2XL Solar PV Fuse Base
  • 1000VDC 400A NH2XL Solar PV Fuse Base1000VDC 400A NH2XL Solar PV Fuse Base

1000VDC 400A NH2XL Solar PV Fuse Base

The YRPV-400D 1000VDC NH2XL PV Fuse Holder is specifically designed for protecting and isolating Photovoltaic (PV) array combiners and DC disconnects. The recommended fuse link size is YRPV-400D 1000VDC NH2XL Fuse Link, which can protect 1000VDC Photovoltaic (PV) systems safely. 1000VDC 400A NH2XL Solar PV Fuse Base is suitable for PV inverter protection and array combiner applications. The compact size of YRPV-400D 1000VDC NH2XL PV Fuse can saving more space and the steel plate enables high strength and durability. The NH screw mounting fit most installation in the cabinet of the Photovoltaic (PV) system.

Send Inquiry

Product Description

1000VDC 400A NH2XL Solar PV Fuse Base

Approvals & Standards

• IEC60269-6
• EN60269-6

Class of Operation

• gPV

Features & Benefits

• YRPV-400D 1000VDC NH2XL Fuse Link recommended
• 1000VDC Photovoltaic (PV) system available
• 400A ampere ratings
• Meets IEC IEC60269-6 standard for global acceptance
• Steel plate enables high strength and durability
• Low temperature rise for better performance of the circuit protection
• NH screw mountable

Applications

• Combiner box
• PV array protection
• Inverters
• Re-combiner units
• In-line PV module protection

Recommendations:

• Do not operate under load
• Use 75°C CU wire only

Country of Origin

• People's Republic of China

Parameters

Product code Rated current Rated voltage Safety certificate Recommended Fuse Link Model/Size Net weight



YRPV-400D 400A 1000Vdc YRPV-400D 0.685g

Note:●DENOTES FOR CERTIFICATION APPROVED;○DENOTES FOR PENDING CERTIFICATION

Size (mm)
