690VAC 100A NH000 HRC Fuse
China fuse manufacturer Galaxy Fuse’s (Yinrong) 690VAC 100A NH000 HRC Fuse primarily protects cables and conductors against overload and short-circuit currents and is also suitable for the protection of equipment with different operating classes such as gG/gL, aM and aR. This square body with blade terminals fuse was made in a standardized configuration for global acceptance. 690VAC 100A NH00C HRC Fuse is available in multiple ampere ratings from 4A up to 100A, which helps match specific requirements in various industrial applications, such as motors, transformers, low voltage distribution, control circuits, etc.
Send Inquiry
Product Description
690VAC 100A NH000 HRC Fuse
Approvals & Standards
• IEC60269-1
• IEC60269-2
Class of Operation
• gG/gL
• aM
• aR
Features & Benefits
• Covering 500VAC, 690VAC, 800VAC and 1140VAC electrical distribution circuits and various industrial applications
• 4-100A ampere ratings available
• Full range protection
• Meets IEC standards for global acceptance
• Standardized square body with blade terminals construction
• Low power dissipation performance for lower temperature rise
• Open-ended installation
Applications
• General industrial applications
• Motor drives
• LV-net works
• Electric cabinet
• Solid state relays
• Semiconductor devices
• Power rectifiers
• Uninterruptable Power System
• Converters
Recommended Fuse Holder
• YR:Sist101 (NH00C Fuse Base)Optional Accessories
• NH Fuse Handle (Extractor)Country of Origin
• People's Republic of ChinaParameters
| Model/Size | Rated Voltage (V) | Rated current (A) | Overall Dimension | |||||
|---|---|---|---|---|---|---|---|---|
| A | D | E | H | H1 | H2 | |||
| NH00C | 500/690 | 4, 6, 10, 16, 20, 25, 32, 40, 50, 63, 80, 100 | 78 | 52 | 21 | 53 | 15 | 35 |
| Model/Size | Rated Voltage(V) | Rated current(A) | Overall Dimension |
|---|---|---|---|
| YR:Sist101 | 690 | 160 | Fig.2 |
Size (mm)
