Battery Fuse Holder Manufacturers

The YRPV-63 1500VDC 63A 14×65mm Solar PV DIN Rail Fuse Holder is specifically designed to protect the Photovoltaic (PV) systems. The recommended fuse link is 14×65mm, which secures the 1500VDC Photovoltaic (PV) systems. The YRPV-63 1500VDC 14 x 65mm PV Fuse provides higher amperage protection in smaller spaces. The most commonly used YRPV-63 1500VDC 14×65mm PV Fuse applications include PV combiner boxes, inverters, PV string, PV array protection, etc. YRPV-63 1500VDC 14×65mm PV Fuse Holder was made of the flame-retardant shell with V0 standard, and the dead-front design made it available to fit most busbar mounting in the Photovoltaic (PV) system.

Galaxy Fuse’s (Yinrong) 690VAC 100A Australia Type Clear HRC Cutout Fuse is designed to ensure a secure connection and low contact resistance throughout and is typically used to protect the supply to a flat or a dwelling and used as a service head. Glass-reinforced Polyester (DMC) material provides strength, durability, and excellent tracking resistance.

Galaxy Fuse’s (Yinrong) 690VAC 400A NT2 HRC Fuse is generally designed to cover a wide range of protection for most of industrial applications with different operating class such as gG/gL, aM and aR. This square body with blade terminals fuse was made in a standardized configuration for global acceptance. 690VAC 400A NT2 HRC Fuse is available in multiple ampere ratings from 125A up to 400A, which helps match specific requirements in various industrial applications, such as motors, transformers, low voltage distribution, control circuits and so on.

Galaxy Fuse is a leading China 1000VDC 160A NH0 Solar PV Fuse Base manufacturers. The YRPV-160 1000VDC NH0 PV Fuse Holder is specifically engineered and manufactured to protecting and isolating Photovoltaic (PV) array combiners and DC disconnects. The recommended fuse link size is YRPV-160 1000VDC NH0 Fuse Link, which can effectively protect Photovoltaic (PV) systems under 1000VDC. YRPV-160 1000VDC NH0 PV Fuse is suitable for PV inverter protection and PV array combiner applications. The compact NH0 size of YRPV-160 1000VDC PV Fuse can saving more space and the steel plate enables high strength and durability. The NH screw mounting fits most installation in the cabinet of the Photovoltaic (PV) system.

Galaxy Fuse is a leading China 690V 315A YRSA000-G High Speed Fuse manufacturers. China high speed fuse supplier Galaxy Fuse (Yinrong)’s YRSA000-G high speed fuse is specially designed to protect semiconductor devices. YRSA000-G high speed fuse is designed for short-circuit protection only. YRSA000-G high speed fuse offers a wide amperage rating of 10-315A under the rated voltage of 690V/700VAC, which can meet most semiconductor protection. This YRSA000-G high speed fuse conformed to the nation standard GB13539.4 and the international electrical committee standard IEC60269-4. With a powerful R＆D capacity, Galaxy Fuse (Yinrong) also offers various high speed fuses to meet emerging energy storage applications.

The YRPV-30 1000VDC 10×38mm heighten PV Fuse Holder is designed to fit 1000VDC PV Fuse, which can provide fast-acting protection under overload current conditions associated with Photovoltaic (PV) systems. The total height of the product has been increased from the original 61.5±0.5mm to 70±0.5mm, which can better match the matching circuit breakers and surge protectors, and unify the height of all accessories in the combiner box and other equipment to a horizontal plane, not only It increases safe operation and improves the aesthetics. YRPV-30 1000VDC 10×38mm heighten PV Fuse Holder is also available in 1, 2, 3 and 4-pole configurations.
